Diagram Flows

01 · Password Auth & Hashing

User          Browser         Server          Database
 │                │               │               │
 │─ Enter pw ────▶│               │               │
 │                │─ POST /login ▶│               │
 │                │               │─ Lookup user ▶│
 │                │               │◀─ Return hash ─│
 │                │               │  bcrypt.compare()
 │                │◀─ Set token ──│               │
 │◀─ Access OK ───│               │               │

⚠️ Password is never stored in plaintext. bcrypt adds a random salt automatically.
Tune the cost factor to control how slow (and brute-force-resistant) the hash is.

02 · JSON Web Tokens (JWT)

Client              Auth Server         API Server
 │                       │                   │
 │─ POST credentials ───▶│                   │
 │◀─ JWT (signed) ───────│                   │
 │                       │                   │
 │─ GET /data ───────────────────────────────▶│
 │   Authorization: Bearer <token>            │
 │                       │  verify signature  │
 │◀─ 200 OK + data ──────────────────────────│

Header.Payload.Signature — no DB lookup needed to verify.
Use short-lived access tokens (15 min) + longer-lived refresh tokens stored server-side.

03 · OAuth 2.0 (Authorization Code + PKCE)

User         Your App        Auth Server          Resource Server
 │               │          (Google/GitHub)              │
 │─ Click SSO ──▶│               │                       │
 │               │─ Redirect + code_challenge (PKCE) ───▶│
 │               │               │                       │
 │◀──────────────────── Consent screen ─────────────────│
 │─ Approve ─────────────────────▶│                      │
 │               │◀─ Auth code ───│                      │
 │               │─ Code + verifier ──▶│                 │
 │               │◀─ Access token ─────│                 │
 │               │─ Bearer token ────────────────────────▶│
 │               │◀─ User data ──────────────────────────│

PKCE prevents auth code interception. Your app never sees the user's password.
Scopes limit exactly what data is shared.

04 · Multi-Factor Auth (TOTP)

User           App            Auth Service       TOTP Validator
 │               │                 │                   │
 │─ Username + password ──────────▶│                   │
 │               │◀─ ✓ pw OK, need 2FA ───────────────│
 │◀─ Prompt 6-digit code ─────────│                   │
 │─ Enter TOTP ──▶│               │                   │
 │               │─ Verify code ──────────────────────▶│
 │               │                 │  secret + timestamp│
 │               │◀─ ✓ Valid window → grant session ───│

TOTP codes are valid for ~30-second windows.
SMS is weaker (SIM-swapping). Hardware keys (WebAuthn/FIDO2) are the strongest 2nd factor.

05 · Session Management

Browser              Server              Session Store (Redis)
 │                      │                        │
 │─ POST /login ────────▶│                        │
 │                       │─ Save { userId, roles } ─▶│
 │                       │◀─ sessionId = abc123 ─────│
 │◀─ Set-Cookie: sid=abc123; HttpOnly; Secure; SameSite=Strict
 │                       │                        │
 │─ GET /dashboard ─────▶│  (cookie auto-sent)    │
 │                       │─ Lookup sessionId ─────▶│
 │                       │◀─ Session data ─────────│
 │◀─ 200 OK + page ──────│                        │

HttpOnly blocks JS from reading the cookie.
SameSite=Strict prevents CSRF. Always rotate session ID after login.

06 · Role-Based Access Control (RBAC)

User        Auth Middleware       RBAC Engine         Resource
 │                 │                   │                  │
 │─ DELETE /posts/42 ────────────────▶│                  │
 │                 │─ user.roles vs delete:posts ────────▶│
 │                 │◀─ role=editor → has permission ✓ ───│
 │                 │─ Forward request ────────────────────▶│
 │                 │◀─ Also check: owns post? (ownership) ─│
 │◀─ 200 OK / 403 Forbidden ─────────│                  │

Roles are assigned to users; permissions are assigned to roles — never directly to users.
Always check authorization at the resource level, not just the route level.

07 · Rate Limiting & Brute Force Defense

Attacker       Rate Limiter (Edge)      Auth Server      Anomaly Detector
 │                     │                     │                  │
 │─ 1000 login attempts/min ──────────────▶│                  │
 │◀─ 429 Too Many Requests (after 5 fails) ─│                  │
 │                     │─ Log suspicious IP ───────────────────▶│
 │                     │◀─ Block IP / trigger CAPTCHA ──────────│
 │                     │                     │                  │
 │  (legitimate traffic only)               │                  │
 │─ Login attempt ─────▶│─ Pass through ────▶│                  │

Apply limits per-IP and per-account.
Use exponential backoff with jitter. Alert on distributed attacks (many IPs, same target).

Summary
